C1201 SERIES

产品尺寸：12*12*7.3/4.3/8.0/8.5mm 作动力：2.55N 动作寿命：1千万次 防尘防水 采用了独有的防尘结构和高可靠金属接点的长寿命型开关。 寿命可达1千万次。

PDF Download

C3012 SERIES led tact switch

The area of the button with light switch is, the luminous effect on the front is uniform, and the modeling design has no light spots. It is matched with transparent covers with different shapes and astigmatism films with different colors to make the

PDF Download

C303 SERIES silent led push button switch

The smooth, quiet and silent button switch with light has a clear sense of press rebound, the preloading stroke is sensitive to false touch, the built-in bright RGB full-color LED, the stroke length is 2.5mm, and the cap and laser symbol can be custo

PDF Download

C3026(A) SERIES led push button switch

Switch with led, electronic button switch with lock or reset, SPDT or DPDT switch contact circuit, PCB pin and panel card type, various caps and various high brightness lamp colors.

PDF Download

C303L SERIES led push button switch

The smooth, quiet and silent button switch with light has a clear sense of press rebound, and the preloading stroke is sensitive to false touch. The built-in bright RGB full-color LED has a total height of 19.7mm and a stroke length of 2.5mm. The cap

PDF Download

C3002A SERIES single double speed push button switch

It can be used for medical devices, and the materials meet the medical industry standards. Electrical parameters: 10mA ~ 100mA, 2V DC ~ 30V DC Service life: 50000 cycles service environment: - 40 ° C to 85 ° C

PDF Download

MRT SERIES

Knob switch, also known as band switch or rotary band switch, is mainly used in radio, tape recorder, TV and various instruments. All kinds of household appliances, industrial electronic equipment.

PDF Download

C3002 Series double and single speed switch

It can be used as a single-speed or two-speed switch and is suitable for industrial mechanical remote controls.

PDF Download

C3002A series single and double speed push button switch with led

It can be used for medical devices, and the materials meet the medical industry standards. Electrical parameters: 10mA ~ 100mA, 2V DC ~ 30V DC Service life: 50000 cycles service environment: - 40 ° C to 85 ° C

PDF Download

C3002W Push button switch

CLIMATEGRADE： -30℃-70℃ RATED VALUES: 50MA 12V CONTACT RESISTANCE: 50MΩ DIELECTRIC STRENGTH: 250VAC 1 MIN INSULATION RESISTANCE: ≥100MQ OPERATING FORCE1: 600±130GF OPERATING FORCE1: 400±100GF OPERATINGPOSITION1: 7.1+0.2mm OPERATINGPOSITION2: 6

PDF Download

C3002 series SPDT push button switch

3 way switch,suitable for all kinds of heavy machinery and equipment.

PDF Download

TU-D series detector switch

Contact Rating: 50uA，3V DC to 10mA,5V DC Contact Resistance 1Ω max Insulation resistance 100 MΩ min Dielectric strength: 100V AC/1 minute Operating force: 40gf max Travel: 60°

PDF Download
