ASW-15D automotive switch

ON-OFF; SPST; 20A 12VDC; Equipped with a light switch; 3-pin copper alloy, silver plated gold terminals; Black plastic shell; Black, silver plated elongated handle

PDF Download
ASW-14D automotive switch

ON-OFF; SPST; 20A 12VDC; Equipped with a light switch; 3-pin copper alloy terminal; Red shell, red plastic flat handle

PDF Download
ASW-13 automitive switch

20A 12VDC/10A 125VAC; 0N-OFF; (ON)-OFF; ON-ON; ON-OFF-ON; Instant contact, release to disconnect; 2-pin and 3-pin copper alloy terminals; Black plastic flat handle

PDF Download
ASW-20D automotive switch

ON-ON; Copper alloy 3-pin terminal; Black plastic shell

PDF Download
ASW-05 automotive switch

ON-ON; SPDT; 3A 250V; Mechanical lifespan of 40000 cycles; The working temperature ranges from -25 ℃ to 85 ℃; Black shell

PDF Download
ASW-13D automotive switch

ON-OFF; 20A 12VDC; SPST; 3-pin brass terminal; Equipped with a light switch, the LED colors are red, yellow, green, blue, white, and purple; Flat plastic handle; Stainless steel terminals; Blue casing

PDF Download
ASW -07D automotive switch

ON-OFF; 30A 12VDC; SPST; 3-pin terminal; Equipped with a light switch, the LED colors are red, yellow, green, blue, white, and purple; Flat plastic handle; Stainless steel terminal

PDF Download
ASW automotive switch

ON-OFF; 25A 12VDC; SPST; 3-pin terminal; Equipped with a light switch; The LED colors are red, yellow, green, blue, white, and purple; Circular handle; Copper alloy terminal

PDF Download
SAC automotive switch

Plastic casing; Stainless steel base; 250V 2A ; 2-pin terminal; Mechanical lifespan of over 40000 cycles; Electrical lifespan of over 10000 cycles; The working temperature ranges from -25 ℃ to 85 ℃

PDF Download
PBS automotive switch

250V 2A ; 2-pin terminal; Mechanical lifespan of over 40000 cycles; Electrical lifespan of over 10000 cycles; The working temperature ranges from -25 ℃ to 85 ℃; Stainless steel casing; Circular handle; Silver plated handle; Instant contact, release t

PDF Download
KN3 series medium-sized toggle switch

Contact resistance less than 50m Ω; insulation resistance of 500VDC not less than 1000M; withstand voltage of 1500VAC for one minute; The working temperature ranges from -25 ℃ to+85 ℃; Rubberwood pedestal; Black swing arm; White or black handle:; Nic

PDF Download
MR series small swing arm switch

ON-NONE-OFF; ON-NONE-ON; ON-OFF-ON; ON-NONE-(ON); ON-OFF-(ON); (ON)-OFF-(ON); ON-ON-ON; SPST; SPDT; DPST; DPDT; SP3T; Brass or aluminum alloy, plated or chrome plated handles; Brass or aluminum alloy shaft sleeve; Stainless steel casing; Brass, tin p

PDF Download
23 records 1/2 pages next  1  2
