E80-R Miniature rocker switch
Rated value: 6A @ 125VAC or 28 VDC electrical life: 30000 cycles insulation resistance: 1000m Ω min dielectric strength 1500 V RMS @ sea level operating temperature: - 30 ℃ ~ + 85 ℃
PDF Download
TS40-R Subminiature rocker switch
Rated value: 3A 120VAC or 28 VDC electrical life: 30000 cycles insulation resistance: 1000m Ω min dielectric strength 1500 V RMS @ sea level operating temperature: - 30 ℃ ~ + 85 ℃
PDF Download
T80-R Series miniature rocker switch
Rated value: 15A 125VAC or 28 VDC electrical life: 50000 cycles insulation resistance: 1000m Ω min dielectric strength 1500 V RMS @ sea level operating temperature: - 30 ℃ ~ + 85 ℃
PDF Download
SRLS series rocker switch
Rated value 15A 125VAC or 28 VDC electrical life 50000 cycles insulation resistance 1000m Ω min
PDF Download 4 records 1/1 pages
