TU-D 系列侦测开关

Contact Rating: 50uA，3V DC to 10mA,5V DC Contact Resistance 1Ω max Insulation resistance 100 MΩ min Dielectric strength: 100V AC/1 minute Operating force: 40gf max Travel: 60°

PDF Download

TU 系列侦测开关

Contact Rating: 50uA，3V DC to 10mA,5V DC Contact Resistance 1Ω max Insulation resistance 100 MΩ min Dielectric strength: 100V AC/1 minute Operating force: 40gf max Travel: 60°

PDF Download

LTE 系列侦测开关

Contact Rating: "50uA，3V DCmin. 0.1A, 12V DC max" Contact Resistance 500Ω max Insulation resistance 100 MΩ min 500VDC Dielectric strength: 500V AC/1 minute Operating force: 102±50gf Travel: 4.1±0.3mm Operating Life: 300,000 cycles

PDF Download

KTE 系列检测开关

Contact Rating: 1mA~100mA, ≤25V DC Contact Resistance "Free position(680Ω±1.5%) 8.3mm~9.15mm(3380Ω±1.5%) 6.85mm~8.0mm(＜＝500mΩ)" Insulation resistance 100 MΩ min 500VDC Dielectric strength: 250V AC/1 minute Operating force: Actuating Force ≤

PDF Download

JTE 系列检测开关

Contact Rating: 10mA, 5V DC Contact Resistance 1Ω max Insulation resistance 100 MΩ min 100VDC Dielectric strength: 100V AC/1 minute Operating force: 360gf max Travel: 1.3mm

PDF Download

HTE 系列检测开关

Contact Rating: 1mA, 5V DC Contact Resistance 1Ω max Insulation resistance 100 MΩ min 100VDC Dielectric strength: 100V AC/1 minute Operating force: 150gf max

PDF Download

FTE 系列侦测开关

Contact Rating: 1mA, 5V DC Contact Resistance 1Ω max Insulation resistance 100 MΩ min 100VDC Dielectric strength: 100V AC/1 minute Operating force: 105gf max Travel: 2.0mm Operating Life: 100,000 cycles

PDF Download

ESG 系列侦测开关

ESG Series Detector switches Contact Rating: "1mA，5V DC 0.1A, 30V DC " Contact Resistance 1Ω max Insulation resistance 100 MΩ min Dielectric strength: 600V AC/1 minute Operating force: 153gf max

PDF Download

ELU 系列侦测开关

Contact Rating:50uA，3V DCmin. 1mA, 5V DC max" Contact Resistance 3Ω max Insulation resistance 100 MΩ min 100VDC Dielectric strength: 100V AC/1 minute Operating force: 35gf max Travel: 2.50mm Operating Life: 50,000 cycles

PDF Download

ELH 系列检测开关

Contact Rating: "50uA，3V DCmin. 1mA, 5V DC max" Contact Resistance 2Ω max Insulation resistance 100 MΩ min 100VDC Dielectric strength: 100V AC/1 minute Operating force: 35gf max

PDF Download

DTE 系列侦测开关

Contact Rating: 10mA, 5V DC Contact Resistance 2Ω max Insulation resistance 100 MΩ min 100VDC Dielectric strength: 100V AC/1 minute Operating force: 30gf max

PDF Download

CTE 系列侦测开关

Contact Rating: 0.1mA~100mA, 20mV~5V DC Contact Resistance 500mΩ max Insulation resistance 100 MΩ min 250VDC Dielectric strength: 250V AC/1 minute Operating force: 35gf max

PDF Download
