ELH 系列检测开关
Contact Rating: "50uA,3V DCmin. 1mA, 5V DC max" Contact Resistance 2Ω max Insulation resistance 100 MΩ min 100VDC Dielectric strength: 100V AC/1 minute Operating force: 35gf max
PDF DownloadContact Rating: "50uA,3V DCmin. 1mA, 5V DC max" Contact Resistance 2Ω max Insulation resistance 100 MΩ min 100VDC Dielectric strength: 100V AC/1 minute Operating force: 35gf max
PDF DownloadContact Rating: 10mA, 5V DC Contact Resistance 2Ω max Insulation resistance 100 MΩ min 100VDC Dielectric strength: 100V AC/1 minute Operating force: 30gf max
PDF DownloadContact Rating: 0.1mA~100mA, 20mV~5V DC Contact Resistance 500mΩ max Insulation resistance 100 MΩ min 250VDC Dielectric strength: 250V AC/1 minute Operating force: 35gf max
PDF DownloadFeatures: 2.8x3.5mm Operation Direction: Vertical Contact Rating: 1mA, 5V DC Contact Resistance 2Ω max Operating Life: 100,000 cycles
PDF DownloadOperating Temperature: -40°C to 80°C Mechanical life: 1,000,000 cycles Waterproof Grade: IP67(Dust& waterproof)
PDF DownloadDescriptions This Ф19mm self recovery push button is Stainless Steel The front button is Stainless Ste
PDF DownloadFEATURES Vertical and right angle types Miniature size with stainless steel cover Low profile (3.0mm) APPLICATION Instrumentation Industrial automation Building & Home automation
PDF DownloadPole-positions 1P1T,with led,contact rating 12V DC operating force 220±50gf operation life 100000 cycles
PDF DownloadRating:12 VDC 50mA Insulation Resistance:100 mΩ min(DC 250V) Dielectric strength:250VAC (50/60Hz) FOR 1MIN Contact Resistance: 100 mΩ max Electrical life :100,000 cycles Operating Temperature:-20℃ to +70℃
PDF Download面板IP65 防尘防水;红绿蓝黄白五种灯色,5颗LED,共阳极;5个独立轻触开关,共线
PDF Downloadmechanical life :30,000 make and break cycles contact rating:0.4VA max.@20V AC or DC max operating force:250±100gf operating temperature:-40℃to 85℃
PDF DownloadRating:12VDC 50mA Mechanical life:1,000,000 Cycles /10,0000 cycles Contact Resistance: 100mΩ MAX INITIAL Insulation Resistance:100mΩ 500VAC Dielectric strength:250VAC (50/60Hz) FOR 1MIN
PDF Download
